P0562

Symptoms:
P0562-LOW BATTERY VOLTAGE
When Monitored and Set Condition: P0562-LOW BATTERY VOLTAGE
When monitored: With the engine running and the TCM has closed the Transmission Control Relay.
Set condition: If battery voltage at TCM Transmission Control Relay Output Sense circuit is less than 10.0 volts for 15 seconds. *This DTC generally indicates a gradually falling battery voltage or resistive connections to the TCM.

POSSIBLE CAUSES:
RELATED CHARGING SYSTEM DTCS
INTERMITTENT WIRING AND CONNECTORS
FUSED B+ CIRCUIT OPEN OR HIGH RESISTANCE
GROUND CIRCUIT OPEN OR HIGH RESISTANCE
TRANS CONTROL RELAY OUTPUT TO TCM OPEN OR HIGH RESISTANCE
TRANSMISSION CONTROL RELAY OPEN OR HIGH RESISTANCE
TCM - LOW BATTERY VOLTAGE
