No PCI Transmission

Test 1:

Test 2:

SYMPTOM
NO PCI TRANSMISSION

WHEN MONITORED
With the ignition on and the module transmitting information on the PCI BUS.

SET CONDITION
The code will set if the on-board diagnostic cannot detect the module transmitting information on the PCI BUS for 4 consecutive seconds

NOTE: Any PCI Bus Failure will may cause a stored code to set.

POSSIBLE CAUSES
- Airbag control module - ACM
- Left side impact airbag control module - LSIACM
- Right side impact airbag control module - RSIACM
- Stored code or intermittent condition
- Active code present
