Interrogate Right SIACM

Test 1 - 2:

Test 3 - 4:

SYMPTOM
INTERROGATE RIGHT SIACM

WHEN MONITORED
With ignition on, the ACM monitors the PCI Bus for a Right SIACM status message containing the airbag warning indicator On - OFF request. The status message is sent to the ACM once each second or upon any change in the active DTCs.

SET CONDITION
The Code will set, if the ACM receives an Lamp On status message from the Right SIACM

NOTE: This indicates that there is an active diagnostic trouble code in the Right SIACM.

POSSIBLE CAUSES
- Interrogate right SIACM
- No active right SIACM DTCs
- Stored code or intermittent condition
- Active code present
