ABS Lamp Circuit Shorted

Test 1 - 2:

SYMPTOM
ABS LAMP CIRCUIT SHORT

TEST NOTE
This symptom is diagnosed using the test ABS LAMP CIRCUIT OPEN.

WHEN MONITORED
The Instrument Cluster performs an internal diagnostic at power up and when the bulb is requested.

SET CONDITION
When the Instrument Cluster's detects a fault in the ABS bulb circuit.

POSSIBLE CAUSES
- Indicator bulb
- Instrument cluster
