Wiring Diagrams

8w-40-2 (Except Autostick):

8w-40-3 (Autostick):

8w-40-4 (Except DRL):

8w-40-5 (DRL):

8w-40-6:

8w-40-8 (2.0L):

8w-40-9:

8w-40-10:

8w-40-11:

8w-40-12:

8w-40-13:

8w-40-14:

8w-40-15:

8w-40-16:

8w-40-17 (Except Built-Up-Export):

8w-40-18 (Built-Up-Export):

8w-40-19 (Built-Up-Export):

NOTE: To view sheets referred to in these diagrams, see Complete Body and Chassis Diagrams. Electrical Diagrams
