P0725

SYMPTOM
P0725 - ENGINE SPEED SENSOR CIRCUIT

WHEN MONITORED
Whenever the engine is running.

SET CONDITION
Engine RPM less than 390 or greater than 8000 for more than 2 seconds while the engine is running.

POSSIBLE CAUSES
- PCM CKP DTC'S PRESENT
- INTERMITTENT WIRING & CONNECTORS
- CRANK POSITION SENSOR GROUND CIRCUIT OPEN
- CRANK POSITION SENSOR SIGNAL CIRCUIT OPEN
- TCM - ENGINE SPEED SENSOR CIRCUIT
