P1790
P1790
SYMPTOM
P1790 - FAULT IMMEDIATELY AFTER SHIFT
WHEN MONITORED
After a speed ratio error is stored.
SET CONDITION
This DTC is set if the associated speed ratio DTC is stored within 1.3 seconds after a shift.
POSSIBLE CAUSES
-
Fault after shift
