Brake Shoe: Service and Repair
REMOVAL AND INSTALLATION
REMOVAL SERVICE POINT
<> Retainer Removal
Use a flat-tipped screwdriver or a similar tool to open up the retainer joint. Then remove the retainer.
INSTALLATION SERVICE POINTS
>>A<< Wave Washer Installation
Install the washer in the direction shown in the illustration.
>>B<< Retainer Installation
Use pliers or a similar tool to close the retainer end onto the pin.
