P1776

P1776-SOLENOID SWITCH VALVE LATCHED IN LO POSITION

When Monitored and Set Condition:
P1776-SOLENOID SWITCH VALVE LATCHED IN LR POSITION

When Monitored: Continuously when doing partial or full EMCC (PEMCC or FEMCC).

Set Condition: This DTC will set if the TCM senses the L/R Pressure Switch closing while performing PEMCC or FEMCC or after two unsuccessful attempts to perform PEMCC or FEMCC.

PASSIBLE CAUSES:
INCORRECT FLUID LEVEL
RELATED DTC P1784 PRESENT
INTERMITTENT OPERATION
TRANSMISSION RELAY OUTPUT CIRCUIT OPEN
L/R PRESSURE SWITCH SENSE CIRCUIT OPEN
L/R PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
L/R PRESSURE SWITCH SENSE CIRCUIT SHORT TO VOLTAGE
INTERNAL TRANSMISSION - SOLENOID SWITCH VALVE STUCK
TCM - SOLENOID SWITCH VALVE
