P1716

P1716-BUS COMMUNICATION WITH PCM

When Monitored and Set Condition:
P1716-BUS COMMUNICATION WITH PCM

When Monitored: Continuously with ignition key on.

Set Condition: If no bus messages are received from the Powertrain Control Module for 10 seconds.

POSSIBLE CAUSES:
NO COMMUNICATION WITH PCM
OTHER BUS PROBLEMS PRESENT
INTERMITTENT WIRING AND CONNECTORS
TCM - BUS COMMUNICATION
