All Doors (Except Driver) Fail to Unlock

Test 1:




SYMPTOM
ALL DOORS EXCEPT DRIVER FAIL TO UNLOCK

POSSIBLE CAUSES
- Door unlock relay output circuit short to ground remote
- Keyless entry module - unlock relay
