Un-Deployed

REMOVAL
When removing a Passenger Airbag Module for any reason other than DEPLOYMENT:

Disconnect Battery Negative Remote Cable:

1. Disconnect and isolate the battery negative remote cable.

Passenger Airbag Removal:

2. Open and lower glove box fully to gain access to Passenger Airbag Module (PAB) attaching screws inside of the glove box. Glove box removal not required.
3. Disconnect wire connector from the Passenger Airbag Module.
4. Remove the four nuts and two screws attaching airbag assembly to the instrument panel collar.
5. Lift Passenger Airbag Module up and out of panel cavity.

INSTALLATION
For installation, reverse the above procedures. Install a new Passenger Airbag Module and tighten nuts to 11 Nm (100 in. lbs.) and screws to 2 Nm (20 in. lbs.) torque. Refer to Diagnosis and Testing for Airbag System Test procedures before connecting battery negative remote cable.
