Wipers Operate/High Speed Only

Test 1 - 3:




SYMPTOM
WIPERS OPERATE/HI SPEED ONLY

POSSIBLE CAUSES
- HI/LO wiper relay control CKT short/GND
- HI/LO wiper relay
- BCM/HI-LO wiper relay
