Power Window Motor: Service and Repair

REMOVAL

Battery Negative Cable Remove/Install:

1. Disconnect and isolate the battery negative cable.
2. Move the window to the full-up position, if possible.
3. Remove front door trim panel.
4. Remove front door water shield.
5. Remove three screws to front door radio speaker so that motor has room to pivot.
6. Pivot window motor out of door panel.
7. Remove three motor retaining screws to drive cable.
8. Remove motor from drive cable assembly.

INSTALLATION
For installation, reverse the above procedures.
