Automatic Transmission/Transaxle: Diagrams

Drive (First) Half Throttle:

Drive (Second) Half Throttle:

Drive (Third) Not Locked Up:

Drive (Third) Lock-Up:

Drive (Kickdown) Part Throttle:

Second (Manual) Closed Throttle:

Low (Manual) Closed Throttle:

Reverse:
