ORC Passenger Squib 1 Circuit Shorted (Stored)

Test 1:

SYMPTOM
ORC, PASSENGER SQUIB #1 CIRCUIT SHORTED (STORED)

TEST NOTE
This symptom is diagnosed using the test ORC, CALIBRATION MISMATCH (STORED).

WHEN MONITORED
When the ignition is ON, the ORC monitors the resistance of the Passenger Squib # 1 circuits.

SET CONDITION
The ORC has detected low resistance in the Passenger Squib # 1 circuits.

POSSIBLE CAUSES
- Stored code present
- Stored code has become active
