CD Changer Power Supply Too High

Test 1:




SYMPTOM
CD CHANGER POWER SUPPLY TOO HIGH

WHEN MONITORED
Continuously with ignition ON and radio turned ON

SET CONDITION
The code Will set if the radio detects ignition voltage over 16 volts for 5 seconds.

POSSIBLE CAUSES
- Power supply of CD changer
- CD changer power supply too high
