Right Front Sensor Circuit Failure

Symptom:
RIGHT FRONT SENSOR CIRCUIT FAILURE

When Monitored and Set Condition:
RIGHT FRONT SENSOR CIRCUIT FAILURE

When Monitored: Ignition on. The CAB monitors the wheel speed circuit every 7 milliseconds (ms).

Set Condition: If the CAB detects an open or shorted wheel speed sensor circuit, the Diagnostic Trouble Code (DTC) will set.

POSSIBLE CAUSES
RIGHT FRONT WHEEL SPEED SENSOR (+) CIRCUIT OPEN
RIGHT FRONT WHEEL SPEED SENSOR (-) CIRCUIT OPEN
RIGHT FRONT WHEEL SPEED SENSOR (+) CIRCUIT SHORTED TO GROUND
RIGHT FRONT WHEEL SPEED SENSOR (-) CIRCUIT SHORTED TO GROUND
RIGHT FRONT WHEEL SPEED SENSOR (+) CIRCUIT SHORTED TO VOLTAGE
RIGHT FRONT WHEEL SPEED SENSOR (-) CIRCUIT SHORTED TO VOLTAGE
INTERMITTENT CIRCUIT DTC
RIGHT FRONT WHEEL SPEED SENSOR RESISTANCE OUT OF SPECIFICATION
RIGHT FRONT WHEEL SPEED SENSOR DEFECTIVE - SHORTED TO GROUND
CAB DEFECTIVE - RIGHT FRONT WHEEL SPEED SENSOR (+) CIRCUIT OPEN
CAB DEFECTIVE - RIGHT FRONT WHEEL SPEED SENSOR (-) CIRCUIT OPEN
CAB DEFECTIVE - RIGHT FRONT WHEEL SPEED SENSOR (+) CIRCUIT SHORTED TO GROUND
RIGHT FRONT WHEEL SPEED SENSOR OR CONNECTOR DAMAGE
