Left Rear Sensor Circuit Failure

Symptom:
LEFT REAR SENSOR CIRCUIT FAILURE

When Monitored and Set Condition:
LEFT REAR SENSOR CIRCUIT FAILURE

When Monitored: Ignition on. The CAB monitors the wheel speed circuit every 7 milliseconds (ms).

Set Condition: If the CAB detects an open or shorted wheel speed sensor circuit, the Diagnostic Trouble Code (DTC) will set.

POSSIBLE CAUSES
LEFT REAR WHEEL SPEED SENSOR (+) CIRCUIT OPEN
LEFT REAR WHEEL SPEED SENSOR (-) CIRCUIT OPEN
LEFT REAR WHEEL SPEED SENSOR (+) CIRCUIT SHORTED TO GROUND
LEFT REAR WHEEL SPEED SENSOR (-) CIRCUIT SHORTED TO GROUND
LEFT REAR WHEEL SPEED SENSOR (+) CIRCUIT SHORTED TO VOLTAGE
LEFT REAR WHEEL SPEED SENSOR (-) CIRCUIT SHORTED TO VOLTAGE
INTERMITTENT CIRCUIT DTC
LEFT REAR WHEEL SPEED SENSOR RESISTANCE OUT OF SPECIFICATION
LEFT REAR WHEEL SPEED SENSOR DEFECTIVE - SHORTED TO GROUND
CAB DEFECTIVE - LEFT REAR WHEEL SPEED SENSOR (+) CIRCUIT OPEN
CAB DEFECTIVE - LEFT REAR WHEEL SPEED SENSOR (-) CIRCUIT OPEN
CAB DEFECTIVE - LEFT REAR WHEEL SPEED SENSOR (+) CIRCUIT SHORTED TO GROUND
LEFT REAR WHEEL SPEED SENSOR OR CONNECTOR DAMAGE
