Interior - Carpet/Floor Wet
NUMBER: 23-28-00GROUP: Body
DATE: July 7, 2000
SUBJECT:
Passenger Compartment Floor/Carpet Wet
OVERVIEW:
This bulletin involves adding additional sill drain plugs.
MODELS:
1996 - 2000 (JX) Sebring Convertible
SYMPTOM/CONDITION:
Moisture under the passenger compartment carpet or wet carpet.
DIAGNOSIS:
If the passenger compartment floor or carpets are wet inspect the sill drain holes for debris. The sill drain holes are the normal water path from the rear of the convertible top. If debris is present, clean drain holes, and perform the Repair Procedure.
PARTS REQUIRED:
2 05019082AA Plug, Sill Drain
REPAIR PROCEDURE:
1. Remove existing sill plug from the rear of the sill (front of the rear wheel well).
2. Install revised plug/drain, p/n 05019082AA.
3. Repeat procedure on other side of vehicle.
POLICY: Reimbursable within the provisions of the warranty.
TIME ALLOWANCE:
Labor Operation No: 23-50-00-94 Both Sides 0.2 Hrs.
FAILURE CODE: P8 - New Parts
