Harmonic Balancer - Crankshaft Pulley: Service and Repair

1. Remove drive belt splash shield.





2. Remove accessory drive belts.





3. Remove crankshaft center bolt and remove crankshaft damper.
4. Reverse Procedure for Installation and torque bolt to 182 Nm (134 ft. lbs.).
