3 Malfunction Indicator Lamp Does Not Illuminate w/Key On

Inspection Procedure 3:






The check engine malfunction indicator lamp does not illuminate immediately after the ignition switch is turned to ON.

Probable Cause
- Burnt-out bulb
- Defective check engine malfunction indicator lamp circuit
- Malfunction of the PCM
