1, 2 and 3 Digit Codes: 135

Scan Tool 135 (MIL 14):

Trouble Code Number
- Scan tool 135
- General scan tool P1296
- MIL 14

Fault Message
- No 5 Volts to MAP sensor

Background
- The voltage of 5 volts is supplied to the MAP sensor. If this voltage is extremely low, the MAP sensor output deviates from standard value.

Range of Check
- Before starting engine and immediately after stopping engine

Set Condition
- The output voltage of MAP sensor is lower than the specified value.

Probable Cause
- Open 5-volts supply circuit
- Signal circuit shorted to ground
- Sensor failed
- PCM failed
