Error Message

DRBIII ERROR MESSAGE
Under normal operation, the DRB will display one of only two error messages:
- User-Requested WARM Boot
- User-Requested COLD Boot





If the DRB should display any other error message, record the entire display and call the MDS Hotline, or call for information and assistance at 1-800-825-8737. This is a sample of such an error message display:

ver: 2.14
date: 26 Jul93
file: key_itf.cc
date: Jul 26 1993
line: 548
err: Ox1
User-Requested COLD Boot

Press MORE to switch between this display and the application screen.
Press F4 when done noting information.
