Spark Plug: Adjustments
Setting Spark Plug Electrode Gap:
Check the
spark plug
gap with a gap gauge. If the gap is not correct, adjust it by bending the ground -- center electrode.
-
Spark Plug
Gap 0.048 to 0.053 in
