Engine Control Module

Check the powertrain control module (PCM) 60-way connector for the following;
- Spread terminals.
- Stretched or pulled out wires.
- Undertightened or overtightened 60 way connector.
- Tighten the PCM connector to 4 N.m (85 in. lbs.) torque.
- When checking terminal pin outs, refer to the Powertrain Control Module 60-Way Connector Diagram for circuit wire colors and cavity numbers.
