Wiper Switch: Service and Repair

Fig. 26 Windshield Wiper Switch Removal:

FRONT
Exc. Horizon, Omni, Charger & Turismo
1. Disconnect battery ground cable and remove steering wheel, using a suitable puller.
2. On models equipped with intermittent wiper system, remove two screws attaching turn signal lever cover to lock housing and the turn signal lever cover.
3. Remove screw attaching windshield wiper switch and switch.
4. Reverse procedure to install.



Lancer & LeBaron GTS
1. Disconnect battery ground cable.
2. Remove headlight and accessory switch module from instrument panel.
3. Remove two rear wiper and washer switch attaching screws from module, then the switch.
4. Reverse procedure to install.
