Secondary Timing Chain Guide Replacement - Left Side

Secondary Timing Chain Guide Replacement - Left Side

Removal Procedure

1. Remove the engine front cover. Refer to Engine Front Cover Replacement Service and Repair.

2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to Spark Plug Replacement Service and Repair.

3. Remove the left bank secondary camshaft drive chain tensioner. Refer to Secondary Timing Chain Tensioner Removal - Left Side 25. Secondary Timing Chain Tensioner Removal - Left Side.





4. Remove the left bank secondary camshaft drive chain guide. Refer to Secondary Timing Chain Guide Removal - Left Side 27. Secondary Timing Chain Guide Removal - Left Side.

Installation Procedure





1. Install the left bank secondary camshaft drive chain guide. Refer to Secondary Timing Chain Guide Installation - Left Side 114. Secondary Timing Chain Guide Installation - Left Side.

2. Install the left bank secondary camshaft drive chain tensioner. Refer to Secondary Timing Chain Tensioner Installation - Left Side 116. Secondary Timing Chain Tensioner Installation - Left Side.

3. Install the spark plugs. Refer to Spark Plug Replacement Service and Repair.

4. Install the engine front cover. Refer to Engine Front Cover Replacement Service and Repair.
