Trim Panel Replacement - Rear Door - Left

Trim Panel Replacement - Rear Door - Left

Removal Procedure




1. Gently pull out the trim panel at the top of the window opening. Using a long flat-bladed suitable tool, pry the retaining clips apart in order to disengage the clips.
2. Lift the left side rear door trim panel up in order to release the tabs on the left side rear door trim panel.
3. Remove the left side rear door trim panel from the door.

Installation Procedure




1. Align the tabs on the left side rear door trim panel with the slots in the door.
2. Lower the left side rear door trim panel into place.
3. Align the tabs on the left side rear door trim panel with the retaining clips around the window opening.
4. Press the left side rear door trim panel into place in order to engage the retaining clips.
