P0182

DTC P0182

Circuit Description

The fuel tank temperature (FTT) sensor is a variable resistor that measures the temperature of the fuel in the CNG fuel tank. The PCM supplies 5 volts to the FTT signal circuit. This DTC sets when the FTT signal voltage is below the normal operating range of the sensor.

Conditions for Running the DTC

- The ignition is ON.
- The intake air temperature is more than -35°C (-31°F).

Conditions for Setting the DTC

- The fuel tank temperature sensor voltage is less than 0.05 volt.
- The condition exists for more than 5 seconds.

Action Taken When the DTC Sets

- The powertrain control module (PCM) stores the DTC information into memory when the diagnostic runs and fails.
- The malfunction indicator lamp (MIL) will not illuminate.
- The PCM records the operating conditions at the time the diagnostic fails. The PCM stores this information in the Failure Records.

Conditions for Clearing the DTC

- A last test failed, or current DTC, clears when the diagnostic runs and does not fail.
- A history DTC will clear after 40 consecutive warm-up cycles, if no failures are reported by this or any other non-emission related diagnostic.
- Use a scan tool in order to clear the DTC.

Diagnostic Aids

- Use the Temperature vs Resistance table in order to test the FTT sensor at various temperature levels in order to evaluate the possibility of a skewed sensor. A skewed sensor could result in a driveability condition. If the engine has sat overnight, the FTT sensor and the intake air temperature values should display within a few degrees. If the temperatures are not within 3°C (5°F), refer to Fuel Temperature Sensor Output Voltage Versus Temperature Resistance.
- For an intermittent condition, refer to Intermittent Conditions.
