C1255

Circuit Description
This DTC identifies a malfunction within the EBCM.


Conditions for Running the DTC
The ABS conditions are normal.


Conditions for Setting the DTC
An internal EBCM malfunction exists.


Action Taken When the DTC Sets
^ ABS is disabled.


Conditions for Clearing the DTC
^ The condition responsible for setting the DTC no longer exists and the Scan Tool Clear DTCs function is used.
^ 100 drive cycles pass with no DTCs detected. A drive cycle consists of starting the vehicle, driving the vehicle over 16 km/h (10 mph), stopping and then turning the ignition OFF.


Diagnostic Aids
Inspect that the EBCM to BPMV connection is secure, tight, and free from corrosion.
