(Export)

REMOVAL PROCEDURE
1. Remove the engine cover.
2. Disconnect the electrical connector from the vehicle immobilizer module.
3. Remove the plastic fastener retaining the vehicle immobilizer module to the sound insulation.
4. Remove the vehicle immobilizer module from the vehicle.

INSTALLATION PROCEDURE
1. Install the vehicle immobilizer module to the vehicle.
2. Install the plastic fastener in order to retain the vehicle immobilizer module to the sound insulation.
3. Connect the electrical connector to the vehicle immobilizer module.
4. Install the engine cover.
5. Reprogram the key fob. Refer to Programming Key Fob to VIM. Testing and Inspection
6. Inspect the system in order to ensure it is operating correctly.
