Aisin 81-40LE - Automatic Transmission (European Emissions)

DTC P0705 (European Emissions)

DTC Descriptor

This diagnostic procedure supports the following DTC:

DTC P0705 Transmission Range (TR) Switch Circuit

Conditions for Setting the DTC

The transmission control module (TCM) detects more than 2 equal signals from the park/neutral position (PNP) switch circuit for 10 seconds continuously.

Action Taken When the DTC Sets

* TCM will request the illumination of malfunction indicator lamp (MIL) and store the DTC when the TCM detects failures on 2 consecutive ignition cycles
* TCM judges with the priority-D>2>L>R>N>P
* No timing solenoid control for N-D
* No self-learning control
* No lockup
* No prevent reverse gear control

Conditions for Clearing the DTC

* The TCM turns off the MIL when no further failures are detected on the next ignition cycles.
* The scan tool can clear the DTC from the TCM history.
* The TCM clears the DTC from the TCM history memory after 40 consecutive ignition cycles without fault.
* The TCM detects single of the PNP switch.

Cause of Failure

* Wiring harness or connector between PNP switch and TCM
* PNP switch
* TCM
