Air Cleaner Intake Duct Replacement



AIR CLEANER INTAKE DUCT REPLACEMENT

REMOVAL PROCEDURE




1. Remove the right front tire and wheel.
2. Remove the right front fender liner.
3. Remove the air cleaner intake duct retainer.
4. Remove the air cleaner intake duct bolt.
5. Remove the air cleaner intake duct.

INSTALLATION PROCEDURE




1. Position the air cleaner intake duct.
2. Install the air cleaner intake duct bolt.

NOTE: Refer to Fastener Notice.

Tighten the bolt to 10 N.m (89 lb ft).

3. Install the air cleaner intake duct retainer.
4. Install the right front fender liner.
5. Install the right front tire and wheel.
