Sunroof / Moonroof: Adjustments

SUNROOF WINDOW HEIGHT AND OPENING FIT ADJUSTMENT

1. Open the sunshade.
2. Close the sunroof window.




3. Loosen the adjusting screws.
4. Adjust the corners of the glass panel (3) using the following guidelines:
- Adjust the front of the sunroof window (2) flush to 1 mm (0.04 in) below the top surface of the roof panel.
- Adjust the rear of the sunroof window (1) flush to 1 mm (0.04 in) above the top surface of the roof panel.

5. Install the sunroof window adjustment screws.

NOTE: Refer to Fastener Notice.

Tighten the sunroof window adjusting screws to 6 N.m (53 lb in).
