Idle Air Control (IAC) System Diagnosis

Idle Air Control (IAC) System Diagnosis

Circuit Description

The engine control module (ECM) controls the engine idle speed by adjusting the position of the idle air control (IAC) valve pintle. The IAC valve is a stepper motor driven by 2 internal coils. The movement of the IAC valve is controlled electrically by 4 circuits. Drivers within the ECM control the polarity of the 2 windings inside the IAC valve through these circuits. The ECM, by commanding the correct polarity in sequence, is able to command the motor within the IAC valve to rotate clockwise or counter clockwise in steps. In order for the armature of the stepper motor of the IAC valve to turn one revolution, it needs to move approximately 24 steps. The IAC valve motor is linked by a gear drive to the IAC valve pintle. The electrical pulses sent to the IAC valve coils, by the ECM, allows the pintle to extend or retract into the passage in the throttle body. By retracting the pintle, air is allowed to bypass the throttle valve, which will increase air flow and raise engine speed. When the pintle is extended, bypass air is decreased which lowers engine speed. IAC valve movement is measured in counts on the scan tool. Each count is equivalent to a step of the IAC valve. When the IAC valve is fully extended, and seated in the throttle body bore, the scan tool displays zero and the engine speed is slow. As the IAC valve pintle retracts the counts will raise along with engine speed.

IAC Valve Reset

When the ignition switch is turned OFF for more than 10 seconds an IAC valve reset occurs. At that time, the ECM commands the IAC valve to extend for a certain period which allows the IAC pintle to seat in the throttle body bore. This position is then sensed as zero count position for the IAC valve by the ECM. It must be observed that the IAC valve position is only sensed by the ECM measuring counts or steps of the driver circuit, there is no direct sensing of its exact position. When this extend time period ends, the ECM then commands the IAC valve to retract a predetermined amount. This will allow for a high engine speed on the next ignition cycle. If for any reason the IAC valve pintle moves after this reset, before the next ignition cycle, the ECM will not be able to detect it and will affect the ability to control engine idle. When the IAC valve is removed or replaced for any reason the reset must be performed. Refer to Idle Learn Testing and Inspection.

Diagnostic Aids

* A low, high, or unstable idle condition could be caused by a non-IAC system condition that cannot be overcome by the IAC valve. Refer to Symptoms - Engine Controls Symptoms - Engine Controls.
* If the condition is intermittent, refer to Intermittent Conditions Intermittent Conditions.
