Instrument Panel Components - Right Side

Instrument Panel/Center Console Component Views



Instrument Panel Components - Right Side





1 - S78 - Turn Signal/Multifunction Switch

2 - P16 - Instrument Cluster

3 - P19H - Speaker - Left Front Tweeter

4 - S38 - Ignition Mode Switch

5 - S48C - Multifunction Switch 1 - Instrument Panel

6 - P19B - Speaker - Center Instrument Panel

7 - B10B - Ambient Light/Sunload Sensor

8 - P19V - Speaker - Right Front Tweeter

9 - E1H - Accent Lamp - Right Instrument Panel

10 - E27 - Instrument Panel Compartment Lamp

11 - S48D - Multifunction Switch 2 - Instrument Panel

12 - A11 - Radio

13 - X80G - Accessory Power Receptacle - Instrument Panel

14 - E1G - Accent Lamp - Left Middle Instrument Panel

15 - S82 - Windshield Wiper/Washer Switch
