C0550

Circuit Description
This DTC identifies a malfunction within the EBCM.

Conditions for Setting the DTC
DTC C0550 is set when an internal EBCM malfunction exists.

Action Taken When the DTC Sets
A malfunction DTC is stored, ABS/TCS is disabled and the ABS and Traction Control Indicators are turned on.

Conditions for Clearing the DTC
^ Condition for DTC is no longer present and scan tool clear DTC; function is used.
^ 100 ignition cycles pass with no DTC(s) detected.
