Driver Side

REMOVAL PROCEDURE

Headlamp Bulb Replacement (Driver Side): Removal Procedure:

1. Open the hood.
2. Unscrew the self-locking tab on the left side radiator cover.
3. Unclip the left side radiator cover from the body to remove the left side radiator cover.
4. Remove the battery.
5. Remove the rubber protective cover from the back of the headlamp to reveal the bulb.

Headlamp Bulb Replacement (Driver Side): Removal Procedure:

6. Separate the bulb fastening tangs (1).
7. Carefully remove the bulb.
8. Remove the electrical connection from the bulb.

INSTALLATION PROCEDURE

Headlamp Bulb Replacement (Driver Side): Installation Procedure:

1. Install the electrical connection to the bulb.
2. Snap the fastening tang (1) in place to install the bulb.
3. Install the rubber protective cover to the back of the headlamp.
4. Install the battery.

Headlamp Bulb Replacement (Driver Side): Installation Procedure:

5. Seat the tab to the body of the left side radiator cover.
6. Secure the left side radiator cover by turning the self-locking tab.
7. Close the hood.
8. Reprogram the applicable accessories.
