Rear Cross-Member: Service and Repair

41 12 548 Stripping Operations - Replacing Rear Crossmember On Luggage Compartment Floor (Tail Panel Removed)







WARNING:
- High-voltage system - danger to life
- Compliance with the following points is mandatory before beginning work:
- De-energise the high-voltage system.
- Observe safety information for handling electric cars.







NOTE: Owing to the different engine variants and equipment specifications, not all the components are taken into consideration.

The following list basically represents the removal sequence.
- Remove battery (FR number: 61 21 010)
- Remove battery negative cable (job number: 61 12 013)
- Remove exhaust system (job number: 18 00 020)
- Remove heat shield
