37 14 512 Replacing Rear Ride-Height Sensor

37 14 512 Replacing rear ride-height sensor





Important!
Read and comply with notes on protection against electrostatic damage (ESD protection).





Disconnect connector connection.

Release nut (1) and disconnect jointed rod.

Tightening torque 37 14 4AZ

Release screws (2) and remove ride-height sensor.

Tightening torque 37 14 3AZ.





After installation:
^ Check headlight setting, correct if necessary
^ Carry out ride-height adjustment (on vehicles with VDC)
