37 14 511 Replacing Front Ride-Height Sensor

37 14 511 Replacing front ride-height sensor





Important!
Read and comply with notes on protection against electrostatic damage (ESD protection).





Release nut (1) and disconnect jointed rod (2).

Tightening torque 37 14 4AZ

Unfasten screws (2).

Tightening torque 37 14 3AZ

Remove ride-height sensor and disconnect plug connection.





After installation:
^ Carry out ride-height adjustment (on vehicles with VDC)
^ Check headlight setting, correct if necessary
