Battery Guard Service - Situations That Trigger A Call
SI B61 04 11General Electrical Systems
March 2012
Technical Service
This Service Information bulletin supersedes SI B61 04 11 dated April 2011.
[NEW] designates changes to this revision
SUBJECT
Battery Guard Service
MODEL
F25 (X3) from March 2011 production
[NEW] F30 (3 Series)
Only vehicles equipped with option 609 (Navigation system) and option code 639 (BMW Assist with Bluetooth) with an active BMW Assist account are eligible.
INFORMATION
An enhancement to the existing Automatic TeleService Calls (ASC) is the introduction of event-triggered calls, based on the ability of the battery to start the vehicle. An Automatic TeleService Call is sent out based on the state of charge of the battery.
There are two situations that might occur in the vehicle to trigger a call:
1. The minimum state of charge of the battery necessary for the vehicle to start has not been reached yet, but if the situation is not corrected right away the vehicle may not start. This situation is caused by the lights (parking or side marker) being left on after the vehicle is parked. This triggers an immediate call to the center. The center can then contact the customer and inform him or her to turn off the lights so the vehicle will be able to start.
2. The minimum state of charge of the battery in order for the vehicle to start has been reached and the vehicle may not start. This situation is caused by a vehicle fault (excessive closed circuit current draw, sleep mode prevented, frequent wakeups or undetermined causes). A TeleService call will be triggered the next time the vehicle is started. The center can then contact the customer and request an appointment in order to troubleshoot the problem before the battery is discharged and the vehicle's ability to start is affected.
However, in many cases, the underlying reason for reaching the low battery state of charge is more subtle and cannot be diagnosed by the transmitted information. In these cases, the center receives a notification about the case, but is also informed that a further analysis is not possible without actual diagnosis on the vehicle using ISTA (Integrated Service Technical Application).
Please be sure to review the Appointment Screen to determine the appropriate steps in handling the TeleService request (see the attachment for an example).
Customer benefits:
^ The customer experiences Premium Service by proactive contact from his or her center, should the vehicle have technical problems.
^ The customer receives direct contact from the center, in case the lights are left on.
^ The customer has fewer battery problems.
Center benefits:
^ The center is directly informed about critical battery problems by TS Battery Guard Call.
^ The center can offer Premium Service by preventing the customer from a breakdown situation.
^ The center is able to compare battery problems with current service information (e.g., in TIS) in advance.
^ In case of breakdowns, the mobile service agent is able to see the history of TeleService Battery Guard calls.
ATTACHMENTS
B610411 attachment
