Removing and Installing/Replacing Locking Unit at Backrest (Backrest Frame Release)




52 24 300 - Removing and installing or replacing locking unit at backrest (backrest frame release)





Necessary preliminary tasks:
- Partially remove backrest cover Replacing Left Backrest Cover for Rear Seat





Release screws (1).
Remove locking unit.
