54 37 050 Removing and Installing/Replacing Trim Strip on Convertible Top Compartment Lid

54 37 050 Removing And Installing/Replacing Trim Strip On Convertible Top Compartment Lid







When working on trim panel components, make sure that the sensitive surfaces are not scratched or damaged.

For purposes of clarity, the following operations are shown with the component removed:







Necessary preliminary tasks:
- Remove trim for soft top compartment lid

Close rear module.







NOTE: Shown removed here for purposes of clarity.

Carefully unclip trim strip (1) from the soft top compartment lid and remove.

Installation:
Replace faulty clips .

Remove remains of butyl rope from trim strip and soft top compartment lid.







Installation:
Install new butyl rope along marking (1).

At each end, finish butyl rope in a "T" shape.
