Gaiter

Gaiter loose

Repair instruction for installation of the gaiter side panel
On installation of the gaiter side panel, attention must be paid to ensuring that the cast-in aluminium strips are not bent. If the aluminium strips are damaged or bent, the gaiter must be replaced, as otherwise no adequate clamping effect is ensured.

Image 1







Cast aluminium strips (1).
