BMW
>>
2008
>>
X3 3.0si (E83) L6-3.0L (N52K)
>>
Repair and Diagnosis
>>
Diagrams
>>
Electrical Diagrams
>>
Body
>>
Seat and Mirror Functions
>>
Seat Adjustment, Driver's Side
>>
Control Module, Seat Memory Supply (SMF, Driver)
Control Module, Seat Memory Supply (SMF, Driver)
Power supply Driver-seat adjuster:
