Home >> BMW >> 2008 >> X3 3.0i (E83) L6-3.0L (N52K) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Wipe and Wash Functions >> Washer Nozzle Heating >> Washer Nozzle Heating (X Series_X3-E83 As of 03/04)

Washer Nozzle Heating (X Series_X3-E83 As of 03/04)

Washer-nozzle heating:
