Removing and Installing/Replacing USB Hub

84 10 050 - Removing and installing/replacing USB hub





Important!
Read and comply with notes on protection against electrostatic damage (ESD protection) 61 35 ... Notes on ESD Protection (Electro Static Discharge).





Necessary preliminary tasks:
- Remove luggage compartment wheel arch trim on left .





Disconnect plug connection (1).
Release screws (2).
Remove USB hub (3).
