Home >> BMW >> 2007 >> Z4 3.0si Coupe (E86) L6-3.0L (N52) >> Repair and Diagnosis >> Diagrams >> Electrical Diagrams >> Body >> Communication >> Universal Charging/Hands-Free Facility (ULF) (ULF Universal Charging and Hands-Free Facility) >> ULF Supply >> Control Module ULF >> Telephone Supply (Z Series_Z4-E85/E86 As of 09/06)

Telephone Supply (Z Series_Z4-E85/E86 As of 09/06)

Telephone supply:
